GE Monogram ZBD1800G User Manual

Safety Information
2
CONTENTS
Installation Preparation
Parts Supplied ....................................................................3
Materials You Will Need ..................................................3
Tools You Will Need ..........................................................3
Prepare Dishwasher Enclosure ......................................4
Drain Requirements ..........................................................5
Prepare Electrical Wiring ................................................6
Prepare Hot Water Line....................................................7
Installation Instructions
Step 1, Check Door Balance............................................8
Step 1A, Adjust Door Springs ..........................................8
Step 2, Adjust Leveling Legs............................................9
Step 3, Remove ToeKick ..................................................9
Step 4, Install Power Cord................................................9
Step 5, Install 90° Elbow ..................................................9
Step 6, Position Water Line and House Wiring ..........10
Step 7, Install Drain Hose Through Cabinet................10
Step 8, Slide Dishwasher Partially Into Cabinet ........10
Step 9, Position Dishwasher Under Countertop ........11
Step 10, Level Dishwasher ............................................11
Step 11, Secure Dishwasher To Cabinet ....................12
Step 12, Connect Water Supply ....................................12
Step 13, Connect Drain Line ..........................................13
Step 14, Connect Power Supply....................................14
Step 15, Pre-Test Checklist ............................................14
Step 16, Dishwasher Wet Test ......................................15
Step 17, Replace Toekick................................................15
Step 18, Literature............................................................15
BEFORE YOU BEGIN
Read these instructions completely and carefully.
•
IMPORTANT — Save these instructions
for local inspector’s use. Observe all governing
codes and ordinances.
• Note to Installer — Be sure to leave these
instructions with the Consumer.
• Note to Consumer — Keep these instructions
with your Owner’s Manual for future reference.
• Skill Level — Installation of this dishwasher
requires basic mechanical and electrical skills.
Proper installation is the responsibility of the
installer. Product failure due to improper installation
is not covered under the GE Appliance Warranty.
• Completion Time — 1 to 3 Hours.
New installations require more time than
replacement installations.
•
IMPORTANT — The dishwasher MUST
be installed to allow for future removal from the
enclosure if service is required.
• If you received a damaged dishwasher, you should
immediately contact your dealer or builder.
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
FOR YOUR SAFETY
Read and observe all CAUTION and WARNINGS shown
throughout these instructions.
While performing installations described in this booklet,
gloves, safety glasses or goggles should be worn.
For Monogram local service in your area, 1.800.444.1845.
For Monogram service in Canada 1.888.880.3030
For Monogram Parts and Accessories, call 1.800.626.2002.
