ZGU375NS
36" natural gas cooktop
ZGU375LS
36" LP gas cooktop
For those who prefer gas heat for
cooking, the Monogram built-in
gas stainless steel cooktop offers
the cooking method of choice.
•Refer to “Installation Preparation” for
information on appropriate placement
and necessary clearances when planning
installation.
•Avoid placing cabinetry directly above
cooktop when possible.
•If cabinetry is used above cooking surface:
–Use cabinets no more than 13" deep.
–Maintain 30" minimum clearance between
cooktop and unprotected cabinets directly
above cooktop.
–If clearance is less than 30", protect cabinet
bottoms with flame-retardant millboard at
least 1/4" thick, or gysum board at least
3/16" thick, covered with 28 gauge sheet
steel or .02" thick copper.
–Clearance between cooktop and protected
cabinetry must not be less than 24".
–An exhaust hood that projects at least 5"
beyond front of cabinets can reduce risk of
burns caused by reaching over heated
surface units.
–Working areas adjacent to the cooktop
should have 18" minimum clearance
between countertop and cabinet bottom.
Advance
planning
Design Information
Stainless Steel Gas Cooktop
•Use the Monogram gas stainless steel cook-
top with any 36" or wider exhaust hood with
350 CFM or greater air flow rating.
•Installation must conform with local codes.
In the absence of local codes, the gas cook-
top must comply with the National Fuel Gas
Code, ANSI Z223.1, latest edition.
3
Dimensions
and clearances
These models are factory set for either natural gas or LP
gas operation. Be sure to order the correct model for the
installation situation.
20-5/8"
Deep
at Center
19-3/4"
36-1/2"
5-1/2"
18-7/8"
3-3/8" Min. From Cutout
to Vertical Combustibles
2-3/4" Min.
35-5/16"
7-9/16" Min. to
Wall From Cutout
18" Min.
13"
Max.
36" Min.
2-3/4" Min.
From Cooktop
to Vertical
Combustible
Surface When
Installed
7" Min. to Wall
From Cooktop Edge
When Installed Both Sides
30"
Min.
