P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
SYSTEM DATA
00
00
This column contains general system settings
Language 00 01 English
English
Francais
Deutsch
Espanol
[Indexed String]
Sets the required language to be used by the device
Password 00 02
4 registers for writing 8 character password
Each register contains a pair of characters
Each register is formatted as follows:-
first character of a pair
second character of a pair
Each character is in the Courier range 33 - 122
[ASCII Password (8)]
Plain text password entry cell
Sys Fn Links 00 03 0
Trip led self reset
[Binary Flag (1) Indexed String]
Setting to allow the fixed function trip LED to be self resetting (set to 1 to extinguish the LED after a period of healthy restoration of load
current).
Description 00 04 MiCOM P54A
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Editable 16 character description of the unit
Description 00 04 MiCOM P54B
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Editable 16 character description of the unit
Description 00 04 MiCOM P54C/P54E
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Editable 16 character description of the unit
Plant Reference 00 05 MiCOM
From 32 to 163 in steps of 1
[ASCII Text (16 chars)]
Editable 16 character plant description
Model Number 00 06 Model Number
Model Number
[ASCII Text (32)]
Displays the model number
Serial Number 00 08 Serial Number
Serial Number
[ASCII Text (7)]
Displays the serial number
Frequency 00 09 50
50 or 60
[Unsigned Integer (16 bits)]
Sets the nominal system frequency
Comms Level 00 0A 1
Comms Level
[Unsigned Integer (16 bits)]
Displays the conformance of the IED to the Courier Level 2 comms.
Relay Address 00 0B 255
From 0 to 255 in steps of 1
[Unsigned Integer (16 bits)]
Sets the first rear port IED address.
Plant Status 00 0C
Plant Status
[Binary Flag (16)]
Displays the circuit breaker plant status.
Control Status 00 0D
Control Status
[Binary Flag (16)]
Not used
Active Group 00 0E 1
Active Group
[Unsigned Integer (16 bits)]
Displays the active settings group
CB Trip/Close 00 10 No Operation
No Operation
Trip
Close
No Operation
