Appendix B - Settings and Signals
P54A/B/C/E
B2
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
No Operation
No Operation
No Operation
No Operation
No Operation
Trip CB2
Close CB2
[Indexed String]
Supports trip and close commands if enabled in the Circuit Breaker Control menu. Visible to LCD+Front Port
CB Trip/Close 00 10 No Operation
No Operation
Trip
Close
No Operation
No Operation
No Operation
No Operation
No Operation
No Operation
Trip CB2
Close CB2
[Indexed String]
Supports trip and close commands if enabled in the Circuit Breaker Control menu. Visible to Rear Port
Software Ref. 1 00 11
Software Ref. 1
[ASCII Text (16)]
Displays the IED software version including protocol and IED model.
Software Ref. 2 00 12
Software Ref. 2
[ASCII Text (16)]
Displays the software version of the Ethernet card
Opto I/P Status 00 20
Opto I/P Status
[Binary Flag (32)
Indexed String]
Displays the status of all available opto inputs fitted.
Relay O/P Status 00 21
Relay O/P Status
[Binary Flag (32)
Indexed String]
Displays the status of all available output relays fitted.
Alarm Status 1 00 22
Setting Group via opto invalid
Test Mode Enabled
Static Test Mode
Loop Back Test Enabled
IM64 Test Enabled
VTS Indication
CTS Alarm
CT2S Alarm
Remote CTS Alarm
Power Swing
BF Block AR
CB Monitor Alarm
CB Lockout Alarm
CB Status Alarm
CB Failed to Trip
CB Failed to Close
Control CB Unhealthy
Control No Checksync
Autoclose Lockout/RLY BAR
No Healthy (AR)
No Check Sync / AR Fail
System Split Alarm
GPS Alarm
Signaling failure alarm
Signaling Propagation Delay Alarm
Differential protection failure alarm
