P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B3
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
IM64 Scheme Fail alarm
IEEE C37.94 Communications Alarms
Diff Protection inhibited
Aid1 Channel Out
Aid2 Channel Out
Frequency out of range
[Binary Flag (32)
Indexed String]
Displays the status of the first 32 alarms as a binary string. Includes fixed and user settable alarms. Data type G96
Alarm Status 1 00 50
Setting Group via opto invalid
Test Mode Enabled
Static Test Mode
Loop Back Test Enabled
IM64 Test Enabled
VTS Indication
CTS Alarm
CT2S Alarm
Remote CTS Alarm
Power Swing
BF Block AR
CB Monitor Alarm
CB Lockout Alarm
CB Status Alarm
CB Failed to Trip
CB Failed to Close
Control CB Unhealthy
Control No Checksync
Autoclose Lockout/RLY BAR
No Healthy (AR)
No Check Sync / AR Fail
System Split Alarm
GPS Alarm
Signaling failure alarm
Signaling Propagation Delay Alarm
Differential protection failure alarm
IM64 Scheme Fail alarm
IEEE C37.94 Communications Alarms
Diff Protection inhibited
Aid1 Channel Out
Aid2 Channel Out
Frequency out of range
[Binary Flag (32)
Indexed String]
32 bit field gives status of first 32 alarms. Includes fixed and user settable alarms.
Alarm Status 2 00 51
BF Block AR 2
CB2 Monitor Alarm
CB2 Lockout Alarm
CB2 Status Alarm
CB2 Failed to Trip
CB2 Failed to Close
Control CB2 Unhealthy
Control No Checksync
Autoclose Lockout/RLY BAR
No Healthy (AR)
No Check Sync / AR Fail
Invalid AR Mode
Incompatible relays
In Valid Message Format
Copro Main Prot. Fail
Configuration Error
Re-Configuration Error
C Diff Protection Comms Mode
Max Prop Delay Alarm
