– 10 –
3. There are 3 posts inserted into the liner ceiling
holding the front of the control in place. Firmly
pull the control housing down at the front edge
to release the posts. Pull the housing towards
the front to release the tabs in the back.
Note: The foam may be holding the posts and
tabs in the liner.
6. Unplug the connector from the control board.
7. Press the tab on the door switch and push the
switch through the hole in the control panel
housing.
4. Unplug the fresh food light connector from the
compartment ceiling.
5. The fresh food light housing is held in place by
4 tabs. Press the tabs to remove the housing.
Components
Knob (Encoder)
Electronic and mechanical control panels are
removed in the same manner.
Removal and Replacement
1. Remove the fresh food light cover.
2. Remove the 2 screws that hold the rear of the
control housing to the liner ceiling.
Connector
Door Switch
