– 4 –
Door Handles
Removal and Replacement
Fresh Food Door
1. Lift the fresh food compartment door handle
firmly upward and off of the 2 door mounting
screws.
2. Reverse the above procedure to reinstall.
Note: The door handle can be installed
incorrectly. Make sure the curved side of the
handle is toward the outside edge of the door.
Freezer Door
1. Install 2 door mounting screws on the freezer
compartment door.
2. Insert the door handle onto the door mount
screws and pull the handle firmly to the left.
Note: The door handle can be installed
incorrectly. Make sure the handle is curved
upward and is locked in place. A properly installed
handle will be centered on the door.
Installation
Doors
The swing direction of the fresh food door and the
freezer door can be reversed on all models except
stainless steel.
Stainless steel models must be ordered as left or
right door swing.
1
2
2
1
To Next Page
