Water Tank
The water tank is located in the refrigerator
compartment, near the bottom left corner. The inlet
water tube is permanently attached to the water
tank. The outlet water tube is connected at the tank,
using a union connector.
To remove the water tank:
Remove the fruit and vegetable crisper drawers 1.
and the crisper drawer cover and frame
assembly.
Remove the two 1/4-in. hex-head screws that 2.
attach the water tank to the left sidewall of the
refrigerator compartment.
3. Disconnect the water tank outlet tube from the
union connector by pressing in the top collar
and pulling out the tubing.
Union Connector
Outlet Water Tube
Top Collar
Water Tank
4. Remove the six 1/4-in. hex-head screws and the
machine compartment cover.
Note: Water will remain in the tank and inlet tube
even when the tank appears empty. Use care to
avoid water spills.
5. Disconnect the water tank inlet tube from the
water valve by pressing in the collar and pulling
the tubing out.
Note: When installing the water tank, push the
outlet tube fi rmly into the union connector. Make
sure that the black mark is fl ush with the top of the
collar.
Black Mark
Collar
