– 49 –

6. Remove the two 1/4-in. hex-head screws that

attach the water tank inlet tube cover to the

rear of the refrigerator.

7. Remove the water tank and inlet tubing from the

refrigerator compartment.

Note: When installing the water tank inlet tube, push

the inlet tube ﬁ rmly into the water valve. Make sure

that the black mark on the tube is ﬂ ush with the

bottom of the collar.

Water Tank Inlet

Tube Cover

Black Mark

Water Dispenser and Interface

The water dispenser assembly incorporates the

interface used for temperature control and features.

The interface has 2 tabs that hold it to the dispenser

shield. The tabs are located above 2 slots located

behind the bottom of the interface.

To remove the water dispenser assembly:

Using a ﬂ at-blade screwdriver, push up on each 1.

tab, then pry the bottom of the interface away

from the dispenser recess.

Slot

(Continued next page)
