Page 2 Protimeter MMS Moisture Measurement System
BLD5800 Kit
The Protimeter MMS instrument is a battery-powered, handheld unit that has
a cluster of four buttons and a large liquid crystal display (LCD). A sensor for
detecting moisture within solid materials is housed in the bulge at the top of
the instrument. The following external connections are found on the
instrument case (see the figure on the next page):
• EC 1 - This edge connection socket is for use with a Hygrostick or
Humistick probe.
• JC - This jack connection socket is for use with a moisture probe, deep
wall probes or a hammer electrode.
• EC 2 - This edge connection socket is for use with the Direct Contact
Surface Temperature Sensor and for connection to a PC when using the
optional MMS logging software.
POU5800-01
POL5800
BLD5802
BLD5804
BLD5018
POL4750
BLD5060
