4 QuickPanel+ User’s Manual–November 2013 GFK-2847
GFK-2847 QuickPanel+ User’s Manual–November 2013 7
Chapter 1 Introduction
Chapter 1. Introduction
The QuickPanel+ operator interface is an all-in-one microcomputer designed for maximum
flexibility. The design, based on an advanced ARM core microprocessor, brings together a
high-resolution touch-screen operator interface with a variety of communications options. You
can connect to most industrial equipment through the QuickPanel+ communications ports.
The QuickPanel+ is equipped with several memory types to satisfy the most demanding
applications. A 512MB section of DRAM is split between the operating system, an object
store and application memory. Functioning as a virtual hard drive, a 256MB section of non-
volatile flash memory is divided between the operating system and persistent storage for
application programs. The retentive memory consists of 512KB of battery-backed SRAM for
data storage, protecting your valuable data during a power failure.
1.1 Specifications
1.1.1 General Specifications
Freescale i.MX535 (1GHz ARM Cortex A8)
512 KB (with Battery backup)
Microsoft Windows Embedded Compact 7
800(W) x 480(H) pixels WVGA
1x RS-232 UART Port (5-Pin Connector)
Two USB2.0 (Type-A)
Max. Power (5V @ 0.5A)
One USB 2.0 (Mini Type-B)
One Mic In (mono) (3.5mm Jack
One Line Out (Stereo) (3.5mm Jack)
Pulse Duration: 1µs, Rise time: 1ns
+24VDC ±20% (3-Pin Connector)
Frame GND is connected to Signal GND internally
