6 QuickPanel+ User’s Manual–November 2013 GFK-2847
Chapter 1. Introduction
1.1.2 Physical Specifications and Mounting
Dimensions (L×W×D)
192 mm × 137 mm × 36 mm
(7.56 in. × 5.39 in. × 1.42 in.)
Weight
0.800 kg (1.76 lbs)
Mounting options
Panel cutout
dimensions
183.5 mm ×128.5 mm
(7.22 in. × 5.06 in.)
VESA mount
VESA Mount: 75 mm x 75 mm
1.1.3 Environmental Specifications
Note: The QuickPanel+ shall be installed in a location that is well ventilated and not exposed
to dust, corrosive gases or liquids, flammable gases, rain, strong ultraviolet light or
direct sunlight, and that meets the environmental specifications listed below.
Cooling
Natural convection
Ambient Operating
temperature
0°C to +50°C
Ambient Storage temperature
-20°C to +60°C
Ambient Humidity (operating
and storage)
85% RH
(non-condensing, wet-bulb temperature:30°C or less)
Environment
Pollution Degree 2 as defined by UL60950-1.
Vibration resistance
5 to 9Hz single-amplitude 3.5mm
9Hz to 150Hz constant-accelerated velocity 9.8m/s
2
X, Y, Z directions 10 time (100minutes)
(Compliance 3502, IEC61131-2 JIS B)
ROHS
Compliant with EU RoHS Directive 2002/95/EC using the following
exemptions identified in the Annex: 7(a), 7(c)-I, & 7(c)-III.
Enclosure rating
IP65 and JEM1030 when installed in accordance with the instructions
in Chapter 4, “Installation.”
Note: For additional product standards and agency approvals, refer to Appendix A.
