2–1–1 Tube–Support Arm
Consists of:
X-ray Tube and Tube Housing Assembly
which has an Up/Down (↑↓) control
located at the top of the Assembly.
The Collimator
consists of the diaphragm and light centering controls.
D Diaphragm Control
Press the control buttons successively on either side of the
collimator to obtain the following:
Large format: 18/24 or 24/30 cm.
Medium format: 13/18 cm.
Reduced format: 9/9 cm.
Press button once to give the last format used and to illuminate the centering light.
D Centering Light
to illuminate the field coverage, press the button located at the
rear of the collimator. The light temporization for medium and small collimator
format for both small and large focal spots (13 x 18, 9 x 9 and 6 x 6) is 120 seconds.
The light temporization for large collimator format (24 x 30 or 18 x 24) is 30 seconds.
D Face protection
is removed from the front of the X–ray Tube and Tube Housing
Assembly.
Push Bar
Push to tilt the X-ray Tube Arm relative to the Receptor-Support Arm when
using the tridimensional Stereotix 2 locating device.
) &' ( ! (" !
' !* ) ( () )
!+ , " ) !!+
D Four angles are available:
+15 degrees and -15 degrees, for making exposures in stereotaxy,
+27 degrees and -27 degrees, to position the puncturing needle or biopsy gun.
Note: When the X-ray Tube Arm is tilted through +15 degrees or -15 degrees,
exposure is authorized only if Stereotix 2 or Senovision Stereotactic positioner
is used. In all other cases, exposure is inhibited, and a warning message is
displayed on the console.
A mechanical structure maintains the Tube-Support Arm balanced and steady.
