2–1–2 Receptor-Support Arm
See Illustration 1–4.
The Receptor-Support Arm consists of the following:
Guide Rail
and Compression system including variable SID, magnification plate,
and compression paddle.
D SID change is made via one of the two levers
located at the bottom of the handrails,
one on either side of the column. Push lever
first to engage the mechanism, then turn
lever
forward to release mechanism and change SID.
- $
Note: The 510-mm SID is reserved for the installation of the Stereotix 2 or
Senovision Stereotactic positioners. With a SID of 510 mm and in the absence
of Stereotix 2 or Senovision Stereotactic positioner, exposure is inhibited and a
warning message appears on the console readout.
D The Magnification Plate
is installed by latching the plate onto the Receptor Arm
in the holes provided for the selected magnification and located on either side of the
Receptor Arm.
To unlock the magnification plate, press the lever located on the left of the mag. plate,
and pull the plate forward (as shown on label on top left side of plate).
Note: Always make sure that the magnification plate is correctly locked in place before
starting an exam.
TABLE 1–1
MAGNIFICATION
.! ! ( ! "# #" $
.! #" " " ! " ) !;
! #" (
!" #
# # $ #
FOR TRAINING PURPOSES ONLY!
