GE Simon XTi

Simon® XTi Installation Guide 11
Household fire warning system (UL 985), basic system plus the
following:
• Wireless smoke sensor 60-848-02-95, TX-6010-01-1
learned into sensor group 26.
• Panel piezo beeps turned on
• Control panel alarms set to on
• Siren timeout set to 4 minutes or more
• Trouble beeps set to on
• RF jam detect set to on
• Hardwired siren supervision set to on
• Smoke supervision set to on
UL 1635 digital alarm communicator system the following
settings are required only if the system is set up for central
station reporting:
• Phone mode 1 set to “All SIA” or “All CID”
• Automatic phone test set to 001
• RF timeout set to 4 hours
• AC power failure report set to on
• CPU low battery report set to on
• Fail to communicate set to on
• Entry delay plus the dialer delay must not exceed 60
seconds
SIA system requirements
Verified to SIA CP-01-2007 by ETL, basic system, plus if
multiple annunciations are required, use hardwired siren 13-
046.
Note: For UL 1635 installations, entry delay plus dialer abort
delay must not exceed 60 seconds.
Table 8 below describes programming requirements to meet
ANSI-SIA CP-01.
Table 8: SIA setting requirements
Function
Default setting
Required setting
Entry delay
30 seconds
30 to 240 seconds
Exit delay
60 seconds
45 to 240 seconds
Dialer delay
30 seconds
15 to 45 seconds
Auto arm
On
On
Un-vacated premises
On
On
Call waiting
Off
On if reporting to
central station and
customer has call
waiting service
Alarm cancel window
6 minutes
6 to 255 minutes, Off
System test
Enabled
Enabled
Communication test
Enabled
Enabled
Exit extension
On
On
Swinger shutdown
On (one trip)
On (one trip)
Function
Default setting
Required setting
Fire alarm verify
Off
On
Duress/panic code
Disabled
Disabled
Cross zone
Disabled
Disabled for zones
with high probability of
false alarms
Table 9 below describes nonprogrammable (hard-coded)
system operation, as required to meet ANSI-SIA CP-01.
Table 9: Nonprogrammable system operation
Function
Operation
Silent exit
All annunciators enabled
Remote arming exit time and
progress annunciation
All annunciators enabled
Abort annunciation
Enabled
Cancel report annunciation
Enabled
Recent closing
Enabled (2-minute window)
Exit error
Enabled
Restoration of power
Panel resumes operation in same
arming state and disregards alarm
signals from sensors for the first
60 seconds after power
restoration
Cancel alarm
Enter code only
Central station reporting
Note: The panel shall not be set or programmed to place a call
to a police station number that has not been specifically
assigned by that police station for such service.
CAUTION: If call waiting is used on a non-call waiting line,
successful connection to the central station may be prevented.
ATTENTION: Si l'appel en attente est utilisé sur une ligne
d'attente non - appel, connexion réussie à la station centrale
peut être empêché .
The panel has been tested with the following central station
receivers using SIA and Contact ID reporting formats:
Before beginning installation, installers must verify that the
central station is equipped with the following receivers:
• Radionics D6600 central station receiver
• Sur-Gard central station receiver with models SG-DRL2A
and SG-CPM2
• CS5000 digital alarm communicator receiver
