GE SPS-48V User Manual

SPS J200703 L005 – Quick Start Guide
4
Document 850052515 r02 2019 April
GE
Critical Power
SPS –48V Slimline Power Shelf
Models: J2007003L005 - alpha suffixes per Slimline Power System Brochure
Quick Start Guide
Document xxxxxxxxxx R01 2017 August
4
Step 12 - Configure Controller per Galaxy Pulsar Edge Controller Quick Start Guide
The shelf is equipped with a 100A, 50mV battery shunt and Low Voltage Battery Disconnect (LVBD0.
1. Verify and edit controller basic configuration parameters per site engineering instructions.
2. Verify and edit Battery Shunt Settings to 100A, 50mV.
A. Controller display - follow path: Menu > Configuration > Shunt monitors > Plant Shunt A & Plant Shunt mV.
B. Web Pages or EasyView2 - select: Settings tab > Shunts > Plant Shunt
3. Set Rectifier Current Limit to 24A if two EP1600-UTEZ rectifiers are powered by a single C13 cord.
A. Controller display - follow path: Menu > Configuration > Rectifiers > Current Limit.
B. Web Pages or EasyView2 - select: Settings tab > Rectifiers > Thresholds > Current Limit
Information: Branch Protection Details
SHELF MODELS
BRANCH PROTECTION
North America
CE
HIGH RANGE ONLY
LOW RANGE
HIGH RANGE
J2007003 L005
15A
15A
15A
J2007003 L005A
2 x 15A
2 x 15A
15A
J2007003 L005C
20A
15A
15A
Information: Rectifier Options
Rectifiers - Single phase,
hot-pluggable, fan-cooled
Input
Max. Recommended Input AC Current
per Feed
Output
Vac
Aac
1 – C14
2 – C14
1 – C20
Float Vdc
W
A
1
150027894
EP0500-540W
N/A
ONLY
200 – 240
6.5
15A
10A
20A
48 – 58
540
10
CC109165602
EP1000-UTEZ: 1000W
N/A
ONLY
100 – 120
12
15A
15A
15A
48 – 58
1000
20
N/A &
CE
200 – 240
6
10A
10A
10A
CC109165610
EP1600-UTEZ: 1600W
N/A
ONLY
100 – 120
15
15A
15A
20A
48 – 58
1200
24
N/A &
CE
200 – 240
7.5
10A
10A
10A
1600
32
1 Output Current at 54.5v. Outputs are power limited, not current limited.
2 Set rectifier current limit to avoid possible nuisance tripping
