Oximeter Features and Use
2-3
PI
r
pulsatile value display
Top view
Important: Only Datex-Ohmeda OxyTip+ sensors can be used with this monitor.
The PI
r
pulsatile value.
This number represents the relative perfusion (blood flow) at the
Indicates that the PI
r
pulsatile value is being displayed.
Infrared (IR) transmitter port
Port through which real-time and trend data are transmitted
from the oximeter to the optional printer.
Sensor connector
Receptacle for connecting a Datex-Ohmeda sensor (refer to the
instructions for the sensor).
