30 UR Family Software 5.80 - Release Notes
E UR Engineer software to support the “IEC 61850 configurator” tool
Applicable: VP UR Engineer
Description: The traditional Viewpoint Engineer software (version 3.30) supports the following
functionality.
Standard Functionality Optional-Advanced
functionality
“System Designer” option
Logic Designer
Logic Monitor
Front Panel Report
Comtrade Viewer
System Designer
System Monitor
Connectivity Report
IEC61850 configurator
With UR firmware version 5.80, the standard functionality (Logic designer, Logic monitor, Front panel
report and Comtrade Viewer) of VP Engineer 3.30 evolved to VP UR Engineer 5.80.
All the advanced functionality (System Designer option) of VP Engineer 3.30 is already released and listed
as follows.
Optional-Advanced
functionality
“System Designer” option
Software Version - period
System Designer
5.80 – now available 
System Monitor
5.80 – now available 
Connectivity Report
5.80 – now available 
IEC61850 Configurator
5.71 – previous release

Customers having UR devices with FW version 5.7x or 5.8x should use VP UR Engineer 5.80.
GE Tracking Number: 580-28
G Software exceptions
Applicable: UR Engineer
Description: The following software exceptions have been corrected with firmware release 5.80.
Software Exceptions
• In the FlexLogic Equation Editor, clicking on the 'type' field occasionally
resets the 'syntax' field to its default value
• When printing a settings file, incorrect operands were printed affecting the
following operands:
• 37141302: RESTD GND FT1 OP, RESTD GND FT1 DPO, and RESTD GND
FT1 PKP
• 34616770: BUS 1 BIASED OP A
• When viewing FlexLogic, incorrect operands were displayed. The following
operands were affected: 37618332: FCO Ux/OUT x DOn, FCO Ux/OUT x IOn,
FCO Ux/OUT x VOn33774133: IOC1 OP, IOC1 PKP, IOC1 DPO
•
PMU channels 2 through 7 are not printed
•
Enabling pushbuttons fails when using a basic front panel
• Phase current metering displays incorrect component designations
• Incorrect Russian translations
• Removing a DSP module during file conversion results in a blank setting
and no warning message
• The order code and firmware version were not verified when reading
settings from the device, resulting in an invalid settings file

GE UR series Specifications

General

Type	Protective Relay
Series	UR (Universal Relay)
Frequency Range	50/60 Hz
Manufacturer	GE (General Electric)
Communication Protocols	IEC 61850, DNP3, Modbus
Mounting	Panel
Display	LCD display
Operating Temperature	-40°C to +70°C
Protection Functions	Overcurrent, differential, distance, frequency, voltage
