Default settings of the display 4 Principles of operation
USM 36 Issue 2 (12/2013) 4-17
Selecting the A-scan color
You can choose the color of the A-scan using the function
A-SCAN COLOR (function group CONFIG2 on the sec
-
ond operating level). The color options depend on the se-
lected color scheme (see Section Selecting the color
scheme, page 4-16).
– Switch to the second operating level.
– In the function group CONFIG2, select the function
A-SCAN COLOR.
– Choose the required color for the A-scan.
Selecting the grid
Using the function GRID (function group CONFIG1 on
the second operating level), you can choose a grid for
the A-scan. Two grids, each with and without a ruler at
the bottom edge of the display, are available as options.
– Switch to the second operating level.
– In the function group CONFIG1, select the function
GRID.
– Choose the required grid for the A-scan.
