3.2. List of parameters
Function FN_ Function Description
Unit Range Factory
setting
Note
0 Factory Adjustment 0
1 Accelerate time 0.1 sec 0.1 ~ 999 S 5.0 (1)(3)
Accelerate /
Decelerate Time
2 Decelerate time 0.1 sec 0.1 ~ 999 S 5.0 (1)(3)
Operation mode
3 0: Forward / Stop, Reverse / Stop
1:Run/Stop, Forward / Reverse
1 0 ~ 1 0
Motor direction 4 0: Forward 1: Reverse 1 0 ~ 1 0 (1)
V/F Pattern 5 V/F pattern setting 1 1 ~ 6 1/4 (2)
6 Frequency upper limit 0.1Hz 1.0 ~ 120Hz
1.0 ~ 200Hz
50/60Hz (2)(3)
(4)
Frequency
upper/lower limit
7 Frequency lower limit 0.1Hz 0.0 ~ 120Hz
0.0 ~ 200Hz
0.0Hz (3)
(4)
SPI frequency
8 SP1 frequency 0.1Hz 1.0 ~ 120Hz
1.0 ~ 200Hz
10Hz (3)
(4)
JOG frequency
9 JOG frequency 0.1Hz 1.0 ~ 120Hz
1.0 ~ 200Hz
6Hz (4)
Operation control 10 0:keypad 1: external terminal 1 0 ~ 1 0
Frequency control
11 0:keypad
1:external terminal(0~10v/0~20mA )
2: external terminal ( 4~20mA )
1 0 ~ 2 0
Carrier frequency
12 Carrier Frequency setting 1 1 ~ 5
1 ~ 10
5 (4)
Torque compensation 13 Torque compensation gain 0.1% 0.0 ~ 10.0% 0.0% (1)
Stop method 14 0:decelerate stop, 1:free run stop 1 0 ~ 1 0
15 DC braking time 0.1S 0.0 ~ 25.5S 0.5S
16 DC braking injection frequency 0.1Hz 1 ~ 10Hz 1.5Hz
DC braking setting
17 DC braking level 0.1% 0.0 ~ 20.0% 8.0%
Electronic thermal
18 Protection on motor rated current 1% 50 ~ 100%
(0-200)
100% (4)
19 Multifunction input terminal 1 function 2
Multifunction input
connection point
20 Multifunction input terminal 2 function
1: Jog 2: Sp1
3: Emergency stop
4: External Base Block
5: Reset 6: Sp2
5 (4)
Multi-function output
21 Multifunction output terminal 1: Operating
2: Frequency reached
3: Fault
3
Reverse instruction
22 0: REV run enabled
1: REV run disabled
1 0 ~ 1 0
Momentary power loss 23 0: enabled 1: disabled 1 0 ~ 1 0
Auto restart 24 Number of Auto-restart times 1 0 ~ 5 0
Factory setting
25 010: Constants initialization to 50Hz system
020: Constants initialization to 60Hz system
(2)
SP2 frequency 26 Frequency SP2 0.1Hz 1.0 ~ 200Hz 20 (4)
SP2 frequency 26 Frequency SP3 0.1Hz 1.0 ~ 200Hz 30 (4)
Direct start 28 0: enable 1: disable 1 0 ~ 1 1 (5)
Software version 29 CPU program version
Fault trace 30 Last 3 malfunction memory
(1) Indicate this parameter can be adjusted during running mode
(2) Please refer to Fn_25
(3) If the setting range is above 100, the setting unit becomes 1.
(4) Only for drives with CPU version from 1.9 (check function F_29)
(5) Only for drives with CPU version from 2.1 (check function F_29)
