7-40 VersaMax Modules, Power Supplies and Carriers User's Manual GFK-1504N
7
IC200MDL636
Input Module, 48 V DC Pos/Neg Logic Grouped 32 Points
Module Specifications
Module Characteristics
Points
32 (4 groups of 8)
Module ID
80088008
Isolation:
User input to logic (optical)
and to frame ground
Group to group
Point to point
250 V AC continuous; 1500 V AC for 1 minute
250 V AC continuous; 1500 V AC for 1 minute
None
LED indicators
One LED per point shows individual point ON/OFF
status
OK LED indicates backplane power is present
Backplane current consumption
5 V output: 140 mA maximum
External power supply
None
Thermal derating Refer to associated diagram
Configuration parameters
Input response times
Compatibility
Cimplicity
ME
VersaPro Control
90
CPU
001
CPU
002
CPU
005
CPU
E05
DBI
001
EBI
001
GBI
001
PBI
001
HW,FW vers.
FW release
2.11 1.5 2.4
AA
1.0
AA
1.5
AA
2.1
AA
2.1
AA
1.1
AA
1.0
AA
1.0
AA
1.0
Input Characteristics
Input voltage
0 to 60 V DC, 48 V DC nominal
User input current
1.7 mA typical at 48 V DC, 2.1mA typical at 60 V DC
Input impedance
28KΩ typical
On state voltage
34 V DC to 60 V DC
Off state voltage 0 V DC to 10 V DC
On state current
Off state current
1.0 mA minimum
0 to 0.4 mA maximum
On response time
Off response time
0.5ms maximum
Configurable filter time
0 ms, 1.0ms (default), or 7.0ms
