GE MEDICAL SYSTEMS
D
IRECTION 2300164-100, REVISION 7 VIVID™ 3 PRO/VIVID™ 3 SERVICE MANUAL
7-26 Section 7-3 - Performing Front End (FE) Diagnostics
Figure 7-14 F.B. Tab - FE Diagnostics Dialog Box (RFI Configuration)
Data Flow Map
Test Description Area
Test Area
Comment Area
Tabs
