Chapter 7 - Diagnostics/Troubleshooting 7-31
The Report dialog box contains the following information:
• Test Result Message: Displays the test result.
• FB Elements: Displays a graphic representation of the front board elements, as follows:
• Each element is represented by a button (highlighted in green) that displays the element,
and the channel number that is associated with that element.
• Each button is highlighted yellow when selected.
• Each button is highlighted red if errors were detected for one or more elements.
• Checkboxes: Enable you to manipulate bad channels:
• Show Only Bad Channels: Select this checkbox to display only bad channels in the
Display area.
• Mark bad channel: Select this checkbox to manually mark the currently selected channel
as bad.
6) Check the test result message and proceed as follows:
• If one or more channels were identified as bad, trackball to the Save Report button and press
Select, then contact a GE Medical Systems Service Representative.
• If no channels were identified as bad, mark the channels suspected as being bad as follows:
• Trackball to each of the channels in the Display area and press select.
• Trackball to the Mark bad channel checkbox and press Select.
• Trackball to Save Report and press Select, and contact a GE Medical Systems service
representative.
7) Trackball to the Start Close test button and press Select. The closed FLA jumper test is performed.
and the test results are displayed in the Report dialog box, as shown in
Figure 7-22 on page 7-40.
