The Report dialog box contains the following information:
• Test Result Message: Displays the test result.
• TR4 Modules: Displays a graphic representation of the front board (four groups of TR4
sockets). Each group consists of four TR4 sockets, each socket containing four vectors
(channels), as follows:
• Each vector is represented by a button (highlighted in green) that displays the number of
the socket to which the TR4 is connected.
• Each button is highlighted yellow when selected.
• Each button is highlighted red if errors were detected for one or more channels.
• Checkboxes: Enable you to manipulate bad channels:
• Show Only Bad Channels: Select this checkbox to display only bad channels in the
Display area.
• Mark bad channel: Select this checkbox to manually mark the currently selected channel
as bad.
6) Check the test result message and proceed as follows:
• If one or more channels were identified as bad, trackball to the Save Report button and press
Select, then contact a GE Medical Systems Service Representative.
• If no channels were identified as bad, mark the channels suspected as being bad as follows:
• Trackball to each of the channels in the Display area and press select.
• Trackball to the Mark bad channel checkbox and press Select.
• Trackball to Save Report and press Select, and contact a GE Medical Systems service
representative.
• If no errors were identified, proceed with the next test.
• If no errors were identified but the problem persists, contact your local GE Medical Systems
field engineer for assistance.
• If errors were identified but the results were marginal, perform calibration, as described in the
Calibration section, on page 6-14, and then repeat the test.
• If errors were identified and the results were not marginal, verify that all image port and PCI
bridge cables are connected and functioning properly, as described in Chapter 5 - Components
and Function (Theory)
. If the problem persists, contact your local GE Medical Systems field
engineer for assistance.
7) Trackball to the Exit button and press Select. If required, repeat this test with a different pulser.
