GE MEDICAL SYSTEMS
D
IRECTION 2300164-100, REVISION 7 VIVID™ 3 PRO/VIVID™ 3 SERVICE MANUAL
Chapter 7 - Diagnostics/Troubleshooting 7-41
The Report dialog box includes the following:
• Test Result Message: Displays the test result.
• Pencil Probe Relays: Displays a graphic representation of the eight front board pencil probe
relays, as follows:
• Each relay is represented by a button (highlighted in green) that displays the relay
number.
• Each button is highlighted in yellow when selected.
• Each button is highlighted in red if errors were detected for one or more relays.
• Checkboxes: Enable you to manipulate bad channels:
• Show Only Bad Channels: Select this checkbox to display only the bad channels in the
Display area.
• Mark bad Channel: Select this checkbox to manually mark the currently selected channel
as bad.
5) Check the test result message and proceed as follows:
• If one or more relays were identified as bad, trackball to Save Report and press Select, and
contact a GE Medical Systems service representative.
• If no relays were identified as bad, mark the channels suspected as being bad as follows:
• Trackball to the channel in the Display area and press Select.
• Trackball to the Mark bad channel checkbox and press Select. Repeat as required to
mark additional channels.
• Trackball to Save Report and press Select, and contact a GE Medical Systems service
representative.
6) Trackball to the Start Close test and press Select. The pencil probe test (close) is performed and
the test results are displayed in the Report dialog box, as shown in
Figure 7-23 on page 7-42.
