3-18 Section 3-4 - Preparing for Installation
3-4-3-3 Rear View of the Vivid™ 3 Ultrasound Unit
The following figure shows the Vivid™ 3 ultrasound unit components that are visible from the rear of the
ultrasound unit:
1 Monitor
2 Gel Wells
3 Monitor Connection Panel
4 Left Rear Panel
5 Right Rear Panel
6 Power Cable Storage Hook
7 Circuit Breaker On/Off Switch
8 Ground Screw
9 Power Cable Socket
Figure 3-12 Rear View of the Vivid™ 3
1
3
4
6
7
8
9
5
2
2
