GE MEDICAL SYSTEMS
D
IRECTION 2300164-100, REVISION 7 VIVID™ 3 PRO/VIVID™ 3 SERVICE MANUAL
Chapter 3 - Installation 3-17
9 Foot Brake: Three-position brake, as follows:
• LEFT (P) locks the wheels.
• MIDDLE unlocks the wheels.
• RIGHT (double arrows) locks the swivel action.
10 Footswitch: Configurable footswitch connected to the patient I/O module that enables keyboard
commands to be operated by foot.
11 Gel Holders: Situated on either side of the control console, and on the top surface on either side of
the monitor.
12 Optional storage compartment.
13 On/Off Switch.
14 Alphanumeric Keyboard and Operation Buttons.
15 Cable Hook.
16 Peripherals: The VCR recorder and/or black-and-white printer and/or color printer are positioned on
the peripheral storage area of the control console.
17 CD Read/Write (CDRW) and MO Disk (optional).
18 Rear Castors.
19 Front Castors.
