GE WIU-2 - Connecting the WIU-2

Wiegand Interface Unit Two State (WIU-2)
Installation Manual
12
Connecting the WIU-2
Connect the WIU-2 between the GE controller and access control
reader as indicated in Figure 3.
Figure 3. Sample WIU-2 configuration
It is important to ensure all connections are made prior
to applying power.
WIU-2
Typical controller (M5
shown)
Typical Wiegand
reader
