– 13 –
Field Service Mode
To enter the Field Service Mode, disconnect then
reconnect the electrical power at the wall outlet.
Within 30 seconds, simultaneously press and hold
the Cottons and Start/Pause buttons for 3 sec-
onds. The unit will start and run, but continue to
hold the buttons until the diagnostics mode is
entered. As soon as the test cycle is entered, the
Dual Seven Segment Display (DSSD) displays, in
sequence, the letters Fd (Field Service Diagnos-
tics), EL or GA (for electric or gas dryer type), and
the EEPROM version number. Wait for the DSSD
to turn OFF before proceeding with testing.
To index to the next test position, press the Mixed
Loads button. To return to the previous test
position, press the Easy Care/Perm Press button.
The following tables give the functions for the
subsequent positions.
Test Sequence, Electric Dryer
* See Rods Table
Thermistor Check: E0 displays if no error is in
thermistor circuit. If an error exists, E1 displays. To
verify thermistor, a resistance range of 100K ohms
+/- 10% @ 77 °F should be found between pins 5
and 6 of female connector CN4 at the right side of
the transformer.
noitisoP
DSSD
tuptuO
noitcnuF
laitinI-0dFedoMcitsongaiDdleiF
laitinI-0LEcirtcelE
laitinI-0# rebmuNnoisreVMORPEE
10ErorrEoN,rotsimrehT
11ErotsimrehTdraoBrororrE
20SlamroN,*tiucriCnepO,sdoR
22EdetrohS,*melborPtiucriC,sdoR
3nSrotoMNOsehctiwS
41HretuO,NOsnruT1retaeH
52HrennI,)FFO1(NOsnruT2retaeH
60d)desolCrooD=Cd(nepOrooD
Sensor Rods Check: S0 displays if sensor rods
are open circuit. If a problem exists, E2 displays.
Touch sensor rod with your hand for 20 seconds.
SS displays if capacitor is discharging properly.
Motor Check: Motor switches ON and DSSD
displays Sn.
Heater 1 Check: Turns ON heater 1 and displays
H1.
Heater 2 Check: Turns ON heater 2 and displays
H2.
Door Status Check: Displays d0 for door open or
dC for door closed.
Test Sequence, Gas Dryer
* See Rods Table
Sensor Rods Check: S0 displays if sensor rods
are open circuit. If a problem exists, E2 displays.
Touch sensor rod with your hand for 20 seconds.
SS displays if capacitor is discharging properly.
Motor Check: Motor switches ON and DSSD
displays Sn.
Igniter Check: Turns ON igniter and displays 1n.
Ultra Care Check: Turns ON Ultra Care relay and
displays 2n.
Door Status Check: Displays d0 for door open or
dC for door closed.
noitisoP
DSSD
tuptuO
noitcnuF
laitinI-0dFedoMcitsongaiDdleiF
laitinI-0AGsaG
laitinI-0# rebmuNnoisreVMORPEE
20SlamroN,*tiucriCnepO,sdoR
22EdetrohS,*melborPtiucriC,sdoR
3nSrotoMNOsehctiwS
4n1NOsnruTretingI
5n2NOsnruTyaleReraCartlU
60d)desolCrooD=Cd(nepOrooD
