GE Wizard DPSE592GA0 - Schematics

– 24 –
Schematics
WARNING
POWER MUST BE DISCONNECTED BEFORE SERVICING THE APPLIANCE.
Note: The numbers in the drawing of the PCB
above correspond to the numbers on the
schematic on page 25.
Refer to microfiche for specific model information.
BROWN/WHITE
PURPLE
ORANGE
BROWN
BROWN
GRAY PINK
WHITE
MODEL SELECTOR
BROWN
BLACK
TERMINAL LAYOUT ON PCB, ELECTRIC DRYER
GEA00573
ORANGE
BLUE
BLUE
BLUE
L1
J
16
9
6543 1
N
2A
10
7
8
6 1
BLACK
YELLOW
GRAY
MODELS WIRE COLOR
MODEL SELECTOR CONNECTOR MATRIX CHART
TERMINAL POSITION
DPSE592 WHITE 1-6
DPSE591 YELLOW, RED 1-3, 4-5
DNCD450 BLACK, YELLOW 1-2-3, 4-5
BROWN/WHITE
YELLOW/BLACK
BLACK
BROWN
BLUE
GRAY PINK
WHITE
MODEL SELECTOR
BLACK
BLACK
TERMINAL LAYOUT ON PCB, GAS DRYER
GEA00572
L1
J
169
43 1
N
2A
10
7
8
6 1
YELLOW/BLACK
ORANGE
YELLOW
PURPLE
MODELS WIRE COLOR TERMINAL POSITION
DPSE592 ORANGE, WHITE 1-3, 5-6
DPSE591 YELLOW, WHITE 1-4, 5-6
DNCD450 GRAY, BLACK 1-2, 4-5-6
MODEL SELECTOR CONNECTOR MATRIX CHART
Note: The numbers in the drawing of the PCB
above correspond to the numbers on the
schematic on page 26.
Terminal Layout on PCB, Electric Model DPSE592EA0
Terminal Layout on PCB, Gas Model DPSE592GA0
