pH PID Settings screen
The pH PID Settings screen is opened by tapping PID SETTINGS on the pH Detail screen.
The following illustration shows an example of the pH PID Settings screen.
1
2
3
4
5 6 7 8
FunctionButton/DisplayPart
pH setpoint (SP), text box for input.SP1
Current pH value (process variable, PV) dis-
play for the selected probe.
PV2
pH (controlled variable, CV) display (PID con-
troller output).
CV3
Note:
In Auto mode this value is calculated by the
PLC. In Manual mode, Manual CV is used as
CV.
User-defined CV (controlled variable) value
for pH PID controller output.
Manual CV
1
4
Note:
In Manual mode, the Manual CV value is used
as CV.
Xcellerex XDM 50-1000, XDUO 100-1000 mixers Operating Instructions 29251615 AD 105
4 User interface
4.4 Detail screens
4.4.4 pH screens
