Xcellerex
™
XDM 50-1000, XDUO
100-1000 mixers
Operating Instructions
Original instructions
Translation disc enclosed

Table of Contents

Questions and Answers

  • G
    glenprattDec 1, 2025
    What to do if temperature control unit (TCU) does not receive setpoint data on GE Xcellerex XDM 50?
    • J
      Joyce LoweDec 1, 2025
      If the Temperature Control Unit (TCU) does not receive setpoint data (temperature is not regulated, mixer vessel jacket does not feel warm, TCU does not sound as running): * Ensure the TCU is powered on. * Check the connection between the I/O Cabinet and the PolyScience™ TCU: 1. Hold the clock button on the left side of the TCU until HL is displayed (a few seconds). 2. Press the clock button repeatedly until CC appears on the left display. 3. If the display message is yes, the connection is working properly. 4. If the display message is no, the connection is not functioning. Check the connection cable between the TCU and PLC. * Check the connection between the I/O Cabinet and the Mokon™TCU: 1. Verify that the controller located on the front of the TCU is pow...
  • L
    Lori WhiteAug 23, 2025
    What to do if load cell is not functioning as expected on GE Xcellerex XDM 50 Mixer?
    • J
      Joseph PrattAug 25, 2025
      If the load cell is not functioning as expected, consider the following: * Ensure the load cell is properly connected. * Contact the metrology department to perform a cornering test to determine if a load cell has failed. * Verify that there are no physical obstructions blocking the load cell's motion. * Disengage the jacking bolt. Note that weight measurements are inaccurate if the mixer was filled while the jacking bolt was engaged. * Contact your GE representative if you suspect the configuration on the load cell transmitter is incorrect or corrupt. * Schedule a calibration of the load cells.
  • B
    bonddanielAug 25, 2025
    What to do if weight monitoring error occurs on GE Mixer?
    • K
      Kimberly BennettAug 26, 2025
      If you encounter a weight monitoring error, such as a weight display outside the operational range or a weight alarm triggered when the mixer weight is within range, consider the following: * Contact the metrology department to perform a cornering test to determine if a load cell has failed. * Check for any physical obstructions that may be hindering the load cell's motion. Ensure the mixer vessel legs are free. * Disengage the jacking bolt. Note that inaccurate weight measurements can occur if the mixer was filled while the jacking bolt was engaged. * Contact your GE representative if you suspect the weight transmitter configuration is incorrect or corrupt.
  • H
    Hunter EstradaAug 27, 2025
    What to do if agitator does not start on FlexFactory controlled GE Xcellerex XDM 50?
    • K
      Kathryn ClarkAug 27, 2025
      If the agitator does not start on a FlexFactory controlled mixer: * Enable the agitator. * Tap RESET on the local control software screen and start the agitator when the system has been restarted after emergency shutdown. Note: The agitator cannot be started while the system is in the state E-STOP. * If the system is in Manual mode, set the system to Auto mode and specify the setpoint. Note: When the system is in Manual mode the setpoint is ignored.
  • A
    anthony79Aug 27, 2025
    Why is variable frequency drive (VFD) not functioning as expected in GE Xcellerex XDM 50 Mixer?
    • S
      Stephanie AndersonAug 27, 2025
      The variable frequency drive (VFD) might not be functioning as expected due to: * The motor being overloaded. Acknowledge the agitator fault and attempt to restart the motor. If the error persists, contact GE for service. * The power cable not being connected. Connect the power cable. * The drive is broken. Contact your GE representative to replace the drive.
  • L
    lynnwilsonSep 18, 2025
    What to do if a button on local control panel screen is not working on GE Xcellerex XDM 50?
    • D
      ddorseySep 18, 2025
      Contact your GE representative for possible replacement, as the local control panel screen may be broken.
  • J
    Joseph HughesSep 14, 2025
    What to do if agitator assembly does not fit properly in place on GE Xcellerex XDM 50?
    • D
      Daniel WangSep 15, 2025
      Contact your GE representative to schedule agitator alignment check and maintenance, as the agitator is not properly aligned.
  • A
    aburnsSep 16, 2025
    What to do if the home screen does not show up on the local control panel of GE Mixer?
    • B
      barmstrongSep 16, 2025
      Contact your GE representative for possible replacement, as the I/O Cabinet may be broken.
  • M
    Michelle MoyerSep 7, 2025
    What to do if pH sensor changes are very slow for the application on GE Xcellerex XDM 50 Mixer?
    • S
      Shawn JohnsonSep 7, 2025
      If pH sensor changes are very slow and pH control is not rapid enough for the application, do a study to find the best tuning parameters for your system and available reagents, as the tuning parameters or the concentration of the applied acid or base may not be sufficient.
  • M
    Mrs. Susan JenkinsSep 4, 2025
    What to do if the pump is not turning on GE Xcellerex XDM 50?
    • L
      Leonard HolmesSep 4, 2025
      If the pump is not turning: * Verify that the cause of the E-STOP condition is eliminated, and clear the E-STOP. Try to use the pumps again. * Clear the interlock condition.

Summary

Important User Information

Read This Before Operating the Product

Emphasizes reading the entire manual, keeping it accessible, and operating only as described.

Intended Use of the Product

Specifies that mixers are for biopharmaceutical applications, not medical use, and not for explosive atmospheres.

Prerequisites

Lists necessary user understanding and preparation for operating the mixers safely and correctly.

Regulatory Information

EU Directives

Safety Instructions

Labels

Emergency Procedures

Outlines emergency shutdown procedures for XDM/XDUO mixers and actions for power or communication failures.

Xcellerex XDUO Mixer Interlocks

Explains the interlock conditions and results for the XDUO mixer, including weight and agitator interlocks.

Security Levels

System Description

System Overview

Describes the operating principle of XDM and XDUO mixers for biopharmaceutical mixing applications.

Xcellerex XDM Mixer System Description

Xcellerex XDUO Mixer System Description

Safety Hardware

Describes essential safety systems like emergency stop, labeling, burst disc, interlocks, and fuses.

Mixer Automation and Control

Explains mixer automation for XDM and XDUO, including VFD control and local control software.

User Interface

General Description

Overview of the XDUO mixer's local control software, including home screen and process variable displays.

Adjustment and Control Screens

Alarm Screens

Explains alarm overview and configuration screens, allowing users to manage alarm settings.

Detail Screens

Installation

Site Requirements

Details requirements for space, floor, electrical power, and environmental conditions for installation.

Installation of the Mixer

Connect Temperature Control Unit

Preparation

Stabilize the Mixer Vessel

Explains how to use jacking bolts to engage and disengage them for stabilizing the mixer vessel.

Prepare the Disposable Bag

Prepare and Install the Probes

Details procedures for calibrating pH/conductivity probes, autoclaving probe sheaths, and inserting probes.

Calibrate the Monitors of Xcellerex XDM Mixer

Prepare the Pumps

Operation

Operate Xcellerex XDM Mixer

Provides instructions for starting the system, operating the agitator motor, and monitoring parameters.

Operate Xcellerex XDUO Mixer

Guides on starting the system, logging in/out, connecting to FlexFactory, and managing data logging.

Add Liquid Contents

Details procedures for adding liquids into the disposable bag, including preparation and filling steps.

Add Solid Contents

Explains how to add solid material into the disposable bag, considering aspects like agitation and material grain size.

Finish a Batch Run

Covers steps for collecting the product, removing the disposable bag, and shutting down the system.

Maintenance

Safety Precautions

Highlights safety measures for maintenance, including trained personnel, equipment shutdown, and contamination hazards.

Maintenance Schedules

Outlines user and calibration maintenance schedules, detailing frequency, activity, and performed by.

Lock-Out; Tag-Out (LOTO): Turn-off Procedure

Provides the recommended procedure for safely turning off the instrument using LOTO.

Lock-Out; Tag-Out (LOTO): Turn-on Procedure

Details the recommended procedure for safely turning on the instrument using LOTO.

Cleaning

Hardware Maintenance

Troubleshooting

Agitation, Xcellerex XDM Mixer

Agitation, Xcellerex XDUO Mixer

Local Control Panel

pH Control

pH;Conductivity Monitoring

Pumps

Temperature Control

Weight Monitoring

Reference Information

System Specifications

Temperature Control Unit

Temperature Probe Calibration

Guides on the calibration and adjustment procedures for temperature probes.

Health and Safety Declaration Forms

Appendix D: Privacy and Security

Cyber Security

Discusses the importance of cyber security measures to protect the product and data from threats.

General Cyber Security Requirements

Network Connections

Cyber Security Vulnerability
