Oven Air Vents
Never block the vents (air openings) of the range.
They
provide the air inlet and outlet that are necessary
for the range to operate properly with correct
combustion. Air openings are located at the rear of the
cooktop, at the top
and
bottom of the oven door, and at
the bottom of the range, under the kick panel, storage
drawer or broiler drawer (depending on the model).
Vent appearance and location
vay
Lift-up Cooktop
(on models with standard twin burners)
Clean the area under the cooktop often. Built-up soil,
especially grease, may catch on fire.
To make cleaning easier, the cooktop may be lifted up.
To raise the cooktop:
1. Be sure the burners are turned off.
2. Remove the grates.
3. Grasp the two front burner wells and lift up.
Some models have dual
support rods that will hold
the cooktop up while
you
clean underneath it.
After cleaning under the
cooktop with hot, soapy
water and a clean cloth,
lower the cooktop. Be
careful not to
pin~h
your fingers.
Removable Kick Panel
(on some models)
The kick panel may be removed for cleaning under
To replace, insert the two
the
range.
slots at the bottom of the panel
To remove, lift up the bottom
onto the two tabs at the base
of the panel slightly to disengage
the panel from the tabs at the
-
=
base of the range. Pull the
bottom of the panel forward
until the spring clips are
released at the top of the panel.
u
*b
of the range and push the top
of the panel forward to engage
the spring clips.
‘,
:
t
I
,/
Removable Broiler Drawer
(on some models)
To remove:
1. When the broiler is cool, remove the rack and pan.
2. Pull the broiler drawer out until it stops, then push
it back in about one inch.
3. Grasp the handle, lift and pull the broiler drawer
out. Clean the broiler drawer with hot soapy water.
To replace:
Hold the broiler drawer in the raised position as you
slide it partway into the range. Then lower the drawer
and push it completely closed.
29
