❑ SEAL THE OPENINGS
Seal any openings in the wall behind the range
and in the floor under the range when hookups
are completed.
E CHECK lGNlllON OF SURFACE BURNERS
Surface Burner Ignition
Operation of all cooktop and oven burners
should be checked after the range and gas
supply lines have been carefully checked
for leaks.
Electric I@ition Models
Select a top burner knob and simultaneously
push in and turn to
LITE position. You will hear
a snapping sound indicating proper operation
of the spark module. Once the air has been
purged from the supply lines, burners should
light within 4 seconds. After burner lights,
rotate knob out of the
LITE position. Try each
burner in succession until all burners have
been checked.
1 -
I
Quali~ of Flames
The combustion quality of burner flames needs
to be determined visually.
m~~~~~~~~:mes-
(B) Yellow tips on
outer
cones—
Normal for LP gas
(C) Sofi blue fl~e~
Normal for natural gas
If burner flames look like (A), call for service.
Normal burner flames should look like (B) or
(C), depending on the type of gas you use.
With
LP gas, some yellow tipping on outer
cones is normal.
E CHECK lGNITlON OF OVEN BURNER
Your oven is designed to operate quietly and
automatically. To operate the oven, turn the OWN
SET knob to B~ and the OWN TEMP knob
to a setting above 300°
E After 30-90 seconds, the
oven burner will ignite and burn until the set
temperature is reached. The oven burner will
continue to cycle on and off as necessary to
maintain the oven at the temperature indicated by
the OWN TEMP knob.
To check ignition of the broil burner, turn the
OWN SET knob to BROIL and the OWN
TEMP knob to BROIL. After 30-90 seconds, the
broil burner will ignite.
Electric i@ition models require electrical
power to operate. In case of a power outage, the
oven burners on these models cannot be lit
manually with a match. Gas will not flow unless
the glow bar is hot.
If the oven is in use when a power outage occurs,
the burner will shut off and cannot be
re-lit until
power is restored.
(c(]ntinued next pa,qe)
