GEA F4 Assembly Instructions

40
D
GB
F
E
09702-09.2013-DGbF
11.1 View X, Y
• Oil sight glass
• Connection facility for parallel operation
Position view X:
F2 NH
3
, F3 NH
3
, F4 NH
3
, F5 NH
3,
F14 NH
3
, F16 NH
3
4 hole oil sight glass
Position view Y:
F14 NH
3
, F16 NH
3
Second oil sight glass can be attached as an
option (available as original equipment only)
50
4
5
°
90°
4 x M6, 10 mm deep
mm
Fig. 48
11| Dimensions and connections F-NH
