2
09716-06.2016-DGbFEIT
rCnRu
D
GB
F
E
I
TR
CN
Ru
About these instructions
Read these instructions before assembly and before using the compressor
.
This will a
void
misunder
-
standings
and prevent damage.
Improper assembly and use of the compressor can lead to serious
or fatal injur
y
.
Observe the safety instructions contained in these instructions.
These instructions must be passed onto the end customer along with the unit in which the compres-
sor is installed.
GEA Bock GmbH
72636 Frickenhausen
GEA Bock GmbH
Benzstraße 7
72636 Frickenhausen
Germany
Phone
+49 7022 9454 0
Fax
+49 7022 9454-137
info@gea.com
www
.gea.com
Manufacturer
Contact
1
3
Table of Contents
Default Chapter
3
Table of Contents
3
1 Safety
4
Identification Of Safety Instructions
4
Qualifications Required Of Personnel
4
Safety Instructions
5
Intended Use
5
2 Product Description
6
Brief Description
6
Name Plate
6
Type Key
7
3 Areas of Application
8
Refrigerants
8
Oil Charge
8
Limits of Application
8
N and K Versions
9
Limits of Application R134A
9
Limits of Application R407C
9
TK Version
10
Limits of Application R404A/R507
10
4 Compressor Assembly
11
Setting up
11
Maximum Permissible Inclination
11
V-Belt Drive GB
12
Main Bearing Load
12
Pipe Connections
13
Pipes
13
Operating the Shut-Off Valves
13
Operating Mode of the Lockable Service Connections TR
14
Commissioning
15
Preparations for Start-Up
15
Pressure Strength Test
15
Leak Test
15
Refrigerant Charge
16
Oil Level Check
16
Shaft Seal
16
Shaft Seal, Emptying the Oil Reservoir
17
Avoiding Liquid Shocks
17
6 Maintenance
18
Preparation
18
Work to be Carried out
18
Recommended Spare Parts
18
Integrated Decompression Valve
18
Extract from the Lubricants Table
19
Decommissioning
19
7 Accessories
20
Capacity Regulator
20
Thermal Protection Thermostat
20
8 Technical Data
21
9 Dimensions and Connections
22
10 Installation Certificate
24
11 Service
25
