09716-06.2016-DGbFEITrCnRu

ATTENTION Compressor operation is possible within the limits of application

showninthediagrams.Pleasenotethesignicanceoftheshaded

areas. The limits of application must be observed. Thresholds

should not be selected as design or continuous operating points.

- Max. permissible discharge end temperature: 140°C

- Max. permissible ambient temperature: 100°C

-Max.permissibleswitchingfrequency:12x/h

-A minimum running time of 2 min. at equilibrium (continuous

operation) must be achieved.

Avoid continuous operation near the threshold. Should the com-

pressor happen to be used near the thresholds, we recommend the

useofathermalprotectionthermostat(Accessories,Chap.7).

For operation with capacity regulator:

- Continuous operation, when the capacity regulator is activated,

is not permissible and can cause damage to the compressor.

- The suction gas superheat temperature may need to be reduced

or set individually when operating near to the threshold.

- When the capacity regulator is activated, the gas velocity in the

systemcannotundercertaincircumstancesensurethatsuf-

cient oil is transported back to the compressor.

When operating in the vacuum range, there is a danger of air en-

tering on the suction side. This can cause chemical reactions, a

pressure rise in the condenser and an elevated compressed-gas

temperature. Prevent the ingress of air at all costs!

3| Areas of application

 Thecompressorsarefactory-lledwiththefollowingoiltype:

- for R134a, R404A/R507, R407C FUCHS Reniso Triton SE 55

- for R22 FUCHS Reniso SP 46

Compressorswithesteroilcharge(FUCHSRenisoTritonSE55)aremarkedwithanXinthetype

designation (e.g. FKX40/655N).

3.1 Refrigerants

• HFKW / HFC: R134a, R404A/R507, R407C

• (H)FCKW/(H)CFC: R22

3.2 Oil charge

3.3 Limits of application

INFO

For recharging, we recommend the above oil types. Alternatives are:

see lubricants table, Chapter 6.5.
