8
Installation
Note: The in.stream 2 must be installed at least 4" (100mm) above potential flood level. A clearance of at least 0.75" (19 mm) is
required to have a free heat circulation at the back of the unit.
Note:
• Do not use foil insulation in front of the unit.
• Place the unit far from any radio noise source such as variable speed control and motor.
• If present, install the FM antenna in a vertical orientation and fully deployed.
• This unit is equipped with an automatic audio volume control that is active when temperature inside the enclosure is very high.
Secure the in.stream 2 onto two wall studs.
Firmly attach upper mounting holes one at a time on each
side of the apparatus.
Repeat the process for lower mounting holes.
The following materials are recommended:
4 # 10 screws of appropriate length with round,
truss or pan head.
4 washers 0.5" OD x .0625” thickness
(12 mm OD x 1.5 mm)
4"
(100 mm)
To prevent water from getting inside the device, the in.stream 2 should be installed on a vertical surface as shown below:
in.stream 2 positioning
