Gecko Y Series Startup Guide

9
Parameter Screen Options Description
Output 4 current
--
0 to 15 amps
Current of accessory connected to output 4
*available on in.ye, in.yt and in.xe
Output 5 current
--
0 to 15 amps
Current of accessory connected to output 5
*available on in.ye, in.yt and in.xe
Output 6 current
--
0 to 15 amps
Current of accessory connected to output 6
*available on in.yt
Output 7 current
--
0 to 15 amps
Current of accessory connected to output 7
*available on in.yt
Output 8 current
--
0 to 15 amps
Current of accessory connected to output 8
*available on in.yt
Output 9 current
--
0 to 20 amps
Current of accessory connected to output 9
*available on in.yt
Output 10 current
--
0 to 15 amps
Current of accessory connected to output 10
*available on in.yt
Output 11 current
--
0 to 15 amps
Current of accessory connected to output 11
*available on in.yt
Output 12 current
--
0 to 15 amps
Current of accessory connected to output 12
*available on in.yt
Direct 1 current
--
0 to 5 amps Current of accessory connected to direct output 1
Direct 2 current
--
0 to 5 amps
Current of accessory connected to direct output 2
*available for in.yt
Heater current
--
0 to 17 amps
0 to 23 amps
(in.ye, in.yt and in.xe only)
Current of the heater
CE configuration
UL = 0
CE/AUS/NZ = 1
CE/AUS/NZ or UL
Number of phases in.yj
1 (UL)
1 or 2 (CE)
in.ye and in.yt
Standard
1 (UL)
1, 2 or 3 (CE)
Swim Spa
1 or 2 (UL)
1, 2 or 3 (CE)
in.xe
Standard
1 (UL)
1
or 2 (CE)
Swim Spa
1 or 2 (UL)
1, 2 or 3 (CE)
Number of phases/breaker
Selection of number of phases (in.yj)
UL Menu not available
CE 1 or 2
Selection of number of phases (in.ye and in.yt)
UL Menu not available
CE 1, 2 or 3
UL Swim 1 or 2
CE Swim 1, 2 or 3
Selection of number of phases (in.xe)
UL Menu not available
CE 1 or 2
UL Swim 1 or 2
CE Swim 1, 2 or 3
Input current in.yj
10 to 40A (UL and CE)
10 to 20A (CE)
in.ye and in.yt
Standard
10 to 48A single phase (UL and CE)
10 to 20A dual phase (CE)
10 to 16A triple phase (CE)
Swim Spa
10 to 48A single phase (UL and CE)
10 to 48A dual phase (UL and CE)
10 to 20A triple phase (CE)
in.xe
Standard
10 to 48A single phase (UL)
10 to 40A single phase (CE)
10 to 20A dual phase (CE)
Swim Spa
10 to 48A single phase (UL)
10 to 40A single phase (CE)
10 to 48A dual phase (UL)
10 to 40A dual phase (CE)
10 to 20A triple phase (CE)
Available household current
Maximum input current (in.yj)
1 phase 2 phases 3 phases
UL 40 na na
CE 40 20 na
Maximum input current (in.ye et in.yt)
1 phase 2 phases 3 phases
UL 48 na na
CE 48 20 16
UL Swim 48 48 na
CE Swim 48 48 20
Maximum input current (in.xe)
1 phase 2 phases 3 phases
UL 48 na na
CE 40 20 na
UL Swim 48 48 na
CE Swim 40 40 20
Table 1 (continued) – in.yj, in.ye, in.yt and in.xe
