SERVICE MANUAL FOR PRODUCERS SBR TYPE GC201 Page 3
PPUH „GECO” EDITION I PRINTOUT DATE 18-04-30
I. GENERAL CHARACTERISTICS.
Independent Control Unit called further GC201 is a modern, comfortable and easy to operate appliance.
It was produced using microprocessor technology and automatic surface assembly.
GC201 stabilizes the temperature and controls automatic defrosting. Period of defrosting can be
adjusted to specific ambient conditions. It also has a button for manual defrosting of the evaporator or for quick
freezing of products in the refrigerator. The mode of operation of this button determines the appropriate
parameter.
GC201 has the ability to select work with one or two temperature sensors and has two relay outputs
enabling direct connection for devices operating at 230V with load capacity in accordance with Table 1.
The controller is equipped with sound signaling as standard, which activates when any button is
pressed on the keypad and when an alarm occurs.
In order to provide the user with the comfort of using the controller, capacitive (touch) buttons were
used in the keyboard.
This thermostat does not require special maintenance; the keyboard was made from a special type of foil
resistant to high temperature and most chemicals. It is not permitted to clean it with sharp objects. It is
sufficient to clean the front plate with a wet cloth from time to time.
II. METHOD OF MARKING AND TECHNICAL DATA
Model: GC201.0X
0X – number indicating the version of the controller
01 – two-relay controller with the possibility to configure the device connected to the second relay in the range:
heater / fan / valve. The controller's keypad is made without a light button.
02 - two-relay controller with the possibility to configure the device connected to the second relay in the range:
light / heater / fan / valve. It is a version dedicated to those users who want to use a second relay to control the
light. The controller's keypad keyboard is made with a light button.
03 - single-relay controller controlling the work of a larger power compressor. The controller's keypad is made
without a light button.
04 - one-relay controller controlling the operation of the compressor with a standard 16A relay. The controller's
keypad is made without a light button.
Operating Voltage
230V +10% -15%
Enviroinment Temperature
od +5
o
C do +40
o
C
Humidity
od 20% do 80% RH
Protection Level
IP65 Front side of control panel
Sensors type
NTC 2,2kΩ - range: from -40
0
C to +60
0
C
