I. GENERAL CHARACTERISTICS
WARNING!!! Since this manual applies to two controllers with the same principle of operation, but difference
in the number of relay outputs, in the following part we will refer to the name of only a more complex
regulator GHC201.08.
Independent Control Unit called further GHC201 is a modern, comfortable and easy to operate appliance.
It was produced using microprocessor technology and automatic surface assembly.
GHC201.08 has two thermostats. Each of them can used for heating or cooling or one can be used as a
universal heating-cooling thermostat.
GHC201 has the ability to select work with one or two temperature sensors and has two relay outputs
enabling direct connection for devices operating at 230V with load capacity in accordance with Table 1.
In the GHC201.08 controller there is possibility to define function of every output. Thanks to this feature the
device is very easy to suit depending on its application. The controller can be used for instance: there, where one
need to turn one heater on, as well as there, where one need to control heating and cooling independently or where
one need to control only cooling.
The controller is equipped with sound signaling as standard, which activates when any button is pressed on
the keypad and when an alarm occurs.
In order to provide the user with the comfort of using the controller, capacitive (touch) buttons were used in
the keyboard.
This thermostat does not require special maintenance; the keyboard was made from a special type of foil
resistant to high temperature and most chemicals. It is not permitted to clean it with sharp objects. It is sufficient
to clean the front plate with a wet cloth from time to time.
II. METHOD OF MARKING AND TECHNICAL DATA
Model: GHC201.0X
0X – number indicating the version of the controller
07 – one-relay version of controller
08 – two-relay version of controller
Operating Voltage
230V AC +10% -15%
Enviroinment Temperature
od +5
o
C do +40
o
C
Humidity
od 20% do 80% RH
Protection Level
IP65 Front side of control panel
Sensors type
NTC 2,2kΩ - range: from -40
0
C to +60
0
C
