GEEETECH
www
.geeetec
h.com
T
el: +86 755 2658
41
10
Fax: +86 75
5 2658 4074 -85
8
- 6 -
1-1(front and back images)
Hardware r
esources
12V/24V
15
A
and 12V/24V 10
A
power supply
1 power port for heatbed and 2 for extruder
5 stepper motor input, (3 for X/Y/Z axis, and 2 for extruders)
Extended LCD & SD card interface
6 endstop input(X-MIN ,Y
-MIN ,Z-MIN
和
X-MAX ,Y
-MAX ,Z-MAX)
3 input for thermistor (TEMP1, TEMP2 and
TEMP3)
3 input for12V
cooling fan
5
7
