4. Post-Carbon Filter is provided for a final "polish" to provide great tasting
drinking water.
5. Storage Tank (2.8 Gal) holds filtered water, ready for use.
6. Feed Water Diverter Valve is connected to the cold water line to supply water
to the RO system.
7. Faucet (Standard) used to dispense RO water when needed.
Optional air gap and designer faucets are available.
8. Waste Water Saddle is connected to the drain to remove reject water from
the RO system.
1.RO Membrane
2.Faucet
3.Feed Water Diverter Valve
4.Waste Water Saddle
5.Unit Installation
6.Tubing Connections
7.Sanitize System
8.Flush System and Check Operation
Installation Steps
Installing the Filters
Install the Membrane
Water Inlet
O Rings
RO Membrane
Seal Ring
Membrane
Housing
Drain Water
Outlet
Pure Water
Outlet
Housing
Connection
Housing
Cap
7
