The following components make up your Reverse Osmosis
Drinking Water System:
1. PP Sediment removes larger particles such as sand, silt, and rust.
2. Coconut Carbon removes chlorine in the feed water to protect the reverse
osmosis membrane.
3. Reverse Osmosis Membrane reduces dissolved minerals, metals and salts.
During the process, harmful compounds are separated by the membrane and
the reject water goes to waste (drain).
Parts of the System
3/8" White Tube
3/8" White Tube
Pressure Tank
Feed Water
Drain
1/4" Red Tube
1/4" White Tube
Figure 2.
Typical Installation
Faucet
12
3
4
5
7
6
8
6
