User Guide Electrical Line Shaft for ADV200 Page 25 of 72
Parameter Name
User type
Value
Unit
Min
Max
Access
11116 Els Slip sel
Enumerative
Parameter (def)
Digital
Analog
-
-
-
RWZ
Selector for source of slip value in %.
If set to “Parameter” (default), source of slip is parameter Els Slip.
If set to
“Digital,” digital increase and decrease commands are source of slip. One step of increase or decrease
corresponds to value set in Els Slip Dig Step.
If set to
“Analog”, source of correction is an analog input.
11118 Els Slip
Float
0.00
%
-100
100
RW
Slip value in % when Els Slip sel = Parameter.
11120 Els Slip Time
Float
1.000
S
0
10
ERW
Time of slip change from 0 to 100%.
11122 Els Slip Incr src
Enumerative
Null (def)
Dig inp x
Decomp
Dig inp x X
-
-
-
ERWZ
Selector for source of digital increase command of slip % when Els Slip sel = Digital.
If active simultaneously with decrease command, the slip change is interrupted.
11124 Els Slip Decr src
Enumerative
Null (def)
Dig inp x
Decomp
Dig inp x X
-
-
-
ERWZ
Selector for source of digital decrease command of slip % when Els Slip sel = Digital.
If active simultaneously with increase command, the slip change is interrupted.
11126 Els Slip Analog src
Enumerative
Null (def)
Analog input x
Analog input x X
-
-
-
ERWZ
Selector for source of slip change command when Els Slip sel = Analog.
11128 Els Slip Dig Step
Float
0.10
%
0.01
100
ERW
Percentage step of slip increase/decrease when Els Slip sel = Digital.
11130 Els Slip Dig Hold T
Unsigned short
200
ms
50
5000
ERW
Hold time of slip increase/decrease commands when Els Slip sel = Digital.
If the increase or decrease command is held for a time exceeding Hold time, a subsequent shift step is applied.
11132 Els Slip Reach dest
Enumerative
Null (def)
Pad from 1 to 16
-
-
-
ERWZ
Selector for destination of monitor of slip state reached Els Slip Reach mon
12060 Els Slip An mon
Float
-
%
-
-
ER
Monitor of slip % value from analog source.
12062 Els Slip Incr mon
Boolean
-
-
-
-
ER
Monitor of state of slip % increase digital command.
12064 Els Slip Decr mon
Boolean
-
-
-
-
ER
Monitor of state of slip % decrease digital command.
12066 Els Slip Dem mon
Float
-
%
-
-
ER
Monitor of slip % value set (before increase/decrease ramp).
12068 Els Actual Slip mon
Float
-
%
-
-
R
Monitor of slip % value in use.
12070 Els Slip Reach mon
Boolean
-
-
-
-
R
Monitor of state of selected slip % reached.
Becomes Off at slip change, goes to On at end of slip change ramp. New slip value reached.
