4-12
Group 02- Motor parameters
No. Description Range
Factory
Setting
Unit Note
02-15
Low Frequency Torque
Gain
0~100 50 %
02-16
SLV Without Load Slip
Compensation Gain
0~200 by series %
02-17
SLV With Load Slip
Compensation Gain
0~200 150 %
02-18
SLV With Load Torque
Compensation Gain
0~200 100 %
02-19
SLV Slip
Compensation Select
0: Slip Compensation 1
2: Slip Compensation 2
0
Group 03- Multi function Digital Inputs/Outputs
No. Description Range
Factory
Setting
Unit Note
03-00
Multifunction Input Term. S1
0:Forward/Stop Command or Run
/Stop
0
-
03-01
Multifunction Input Term. S2
1:Reverse/Stop Command Or
REV/FWD
1
-
03-02
Multifunction Input Term. S3
2:Preset Speed 1 (5-02)
2
-
03-03
Multifunction Input Term. S4
3:Preset Speed 2 (5-03)
3
-
03-04
Multifunction Input Term. S5
4:Preset Speed 4 (5-05)
17 -
6:Jog Forward Command
7:Jog Reverse Command
8:Up Command
9:Down Command
10:Acc/Dec 2
11:Acc/Dec Disabled
12:Main/Alternative Run Command
select
13:Main/Alternative Frequency
Command select
14:Rapid Stop ( Decel to stop)
15:Base Block
16:Disable PID Function
17:Reset
18:Auto Run Mode enable
03-05
Reserved
03-06
Up/Down frequency band
0.00~5.00
0.00
Hz
03-07
Up/Down Frequency modes
0:Preset frequency is held as the
inverter stops, and the UP/Down
function is disabled.
0 -
1:Preset frequency is reset to 0 Hz
as the inverter stops.
2:Preset frequency is held as the
inverter stops, and the UP/Down is
available.
03-08
S1~S5 scan confirmation
1~200. Number of Scan cycles
10
ms
03-09
S1~ S5 switch type select
xxxx0:S1 NO xxxx1:S1 NC
00000 -
xxx0x:S2 NO xxx1x:S2 NC
xx0xx:S3 NO xx1xx:S3 NC
x0xxx:S4 NO x1xxx:S4 NC
