4-14
Group 04- Analog signal inputs/ Analogue output functions
No. Description Range
Factory
Setting
Unit Note
04-00
AVI/ACI analog Input
signal type select
AVI ACI
0 -
0:0~10V 0~20mA
1:0~10V 4~20mA
2:2~10V 0~20mA
3:2~10V 4~20mA
04-01
AVI Signal Verification
Scan rate
1~200 50 2ms
04-02
AVI Gain
0 ~ 1000
100
%
*1
04-03
AVI Bias
0 ~ 100
0
%
*1
04-04
AVI Bias Selection
0: Positive 1: Negative
0
-
*1
04-05
AVI Slope
0: Positive 1: Negative
0
-
*1
04-06
ACI Signal Verification
Scan rate
1~200 50 2ms
04-07
ACI Gain
0 ~ 1000
100
%
*1
04-08
ACI Bias
0 ~ 100
0
%
*1
04-09
ACI Bias Selection
0: Positive 1: Negative
0
-
*1
04-10
ACI Slope
0: Positive 1: Negative
0
-
*1
04-11
Analog Output
mode(AO)
0: Output Frequency
1: Frequency Command
2: Output Voltage
3: DC Bus Voltage
4: Motor Current
0 - *1
04-12
Analog Output AO Gain
(%)
0 ~ 1000 100 % *1
04-13
Analog Output AO Bias
(%)
0 ~ 1000 0 % *1
04-14
AO Bias Selection
0: Positive
1: Negative
0 - *1
04-15
AO Slope
0: Positive
1: Negative
0 - *1
04-16
Potentiometer /
frequency curve gain
setting
0~1000 100 % *1
04-17
Potentiometer /
frequency curve bias
(offset) setting
0~100 0 % *1
04-18
Potentiometer /
frequency curve bias
(offset) signe selection
0: Positive
1: Negative
0 - *1
04-19
Potentiometer /
frequency slope of the
curve selection
0: Positive
1: Negative
0 - *1
