Pr. Explanation Settings
Factory
Setting
NOTE
02.07 Up/Down Mode
0: by UP/DOWN Key
1: Based on accel/decel time
2: Constant speed (Pr.02.08)
3: Pulse input unit (Pr.02.08)
0
02.08
Accel/Decel Rate of
Change of UP/DOWN
Operation with
Constant Speed
0.01~10.00 Hz 0.01
a02.09
Source of Second
Frequency Command
0: Digital keypad UP/DOWN keys or Multi-
function Inputs UP/DOWN. Last used frequency
saved.
1: 0 to +10V from AVI
2: 4 to 20mA from ACI or 0 to +10V from AVI2
3: RS-485 (RJ-45)/USB communication
4: Digital keypad potentiometer
0
a02.10
Combination of the
First and Second
Master Frequency
Command
0: First Master Frequency Command
1: First Master Frequency Command+ Second
Master Frequency Command
2: First Master Frequency Command - Second
Master Frequency Command
0
a02.11
Keypad Frequency
Command
0.00 to 600.0Hz 60.00
a02.12
Communication
Frequency Command
0.00 to 600.0Hz 60.00
02.13
The Selections for
Saving Keypad or
Communication
Frequency Command
0: Save Keypad & Communication Frequency
1: Save Keypad Frequency only
2: Save Communication Frequency only
0
02.14
Initial Frequency
Selection (for keypad
& RS485/USB)
0: by Current Freq Command
1: by Zero Freq Command
2: by Frequency Display at Stop
0
02.15
Initial Frequency
Setpoint (for keypad
& RS485/USB)
0.00 ~ 600.0Hz 60.00
02.16
Display the Master
Freq Command
Source
Read Only
Bit0=1: by First Freq Source (Pr.02.00)
Bit1=1: by Second Freq Source (Pr.02.09)
Bit2=1: by Multi-input function
Bit3=1: by PLC Freq command
##
02.17
Display the Operation
Command Source
Read Only
Bit0=1: by Digital Keypad
Bit1=1: by RS485 communication
Bit2=1: by External Terminal 2/3 wire mode
Bit3=1: by Multi-input function
Bit4=1: by PLC Operation Command
##
Group 3 Output Function Parameters
03.00
Multi-function Output
Relay (RA1, RB1,
RC1)
0: No function
1: AC drive operational
2: Master frequency attained
3: Zero speed
4: Over torque detection
8
