Pr. Explanation Settings
Factory
Setting
NOTE
16: PID supervision
17: Forward command
18: Reverse command
19: Zero speed output signal
20: Warning(FbE,Cexx, AoL2, AUE, SAvE)
21: Brake control (Desired frequency attained)
22: Drive ready
23: Desired frequency 2 attained
11.06
Multi-function Input
Terminal (MI7)
11.07
Multi-function Input
Terminal (MI8)
11.08
Multi-function Input
Terminal (MI9)
11.09
Multi-function Input
Terminal (MI10)
11.10
Multi-function Input
Terminal (MI11)
11.11
Multi-function Input
Terminal (MI12)
0: No function
1: Multi-Step speed command 1
2: Multi-Step speed command 2
3: Multi-Step speed command 3
4: Multi-Step speed command 4
5: External reset
6: Accel/Decel inhibit
7: Accel/Decel time selection command
8: Jog Operation
9: External base block
10: Up: Increment master frequency
11: Down: Decrement master frequency
12: Counter Trigger Signal
13: Counter reset
14: E.F. External Fault Input
15: PID function disabled
16: Output shutoff stop
17: Parameter lock enable
18: Operation command selection (external
terminals)
19: Operation command selection (keypad)
20: Operation command selection
(communication)
21: FWD/REV command
22: Source of second frequency command
23: Run/Stop PLC Program (PLC1)
24: Download/execute/monitor PLC Program
(PLC2)
25: Simple position function
26 OOB (Out of Balance Detection)
27: Motor selection (bit 0)
28: Motor selection (bit 1)
0
Group 12: Analog Input/Output Parameters for Extension Card
12.00
AI1 Function
Selection
0: Disabled
1: Source of the 1st frequency
2: Source of the 2nd frequency
3: PID Set Point (PID enable)
4: Positive PID feedback
5: Negative PID feedback
0
0: ACI2 analog current (0.0 ~ 20.0mA)
12.01
AI1 Analog Signal
Mode
1: AVI3 analog voltage (0.0 ~ 10.0V)
1
12.02
Min. AVI3 Input
Voltage
0.0 to 10.0V 0.0
12.03
Min. AVI3 Scale
Percentage
0.0 to 100.0% 0.0
12.04
Max. AVI3 Input
Voltage
0.0 to 10.0V 10.0
