gefran SIEIDrive ADV50-2022 Series

26 ADV50 QS, SW-PW V1.11 / CTL V2.11
Italiano English
Italiano English
Pr. Explanation Settings
Factory
Setting
NOTE
12.05
Max. AVI3 Scale
Percentage
0.0 to 100.0% 100.0
12.06
Min. ACI2 Input
Current
0.0 to 20.0mA 4.0
12.07
Min. ACI2 Scale
Percentage
0.0 to 100.0% 0.0
12.08
Max. ACI2 Input
Current
0.0 to 20.0mA 20.0
12.09
Max. ACI2 Scale
Percentage
0.0 to 100.0% 100.0
12.10
AI2 Function
Selection
0: Disabled
1: Source of the 1st frequency
2: Source of the 2nd frequency
3: PID Set Point (PID enable)
4: Positive PID feedback
5: Negative PID feedback
0
0: ACI3 analog current (0.0 ~ 20.0mA)
12.11
AI2 Analog Signal
Mode
1: AVI4 analog voltage (0.0 ~ 10.0V)
1
12.12
Min. AVI4 Input
Voltage
0.0 to 10.0V 0.0
12.13
Min. AVI4 Scale
Percentage
0.0 to 100.0% 0.0
12.14
Max. AVI4 Input
Voltage
0.0 to 10.0V 10.0
12.15
Max. AVI4 Scale
Percentage
0.0 to 100.0% 100.0
12.16
Min. ACI3 Input
Current
0.0 to 20.0mA 4.0
12.17
Min. ACI3 Scale
Percentage
0.0 to 100.0% 0.0
12.18
Max. ACI3 Input
Current
0.0 to 20.0mA 20.0
12.19
Max. ACI3 Scale
Percentage
0.0 to 100.0% 100.0
12.20
AO1 Terminal Analog
Signal Mode
0: AVO1
1: ACO1 (analog current 0.0 to 20.0mA)
2: ACO1 (analog current 4.0 to 20.0mA)
0
0: Analog Frequency
12.21
AO1 Analog Output
Signal
1: Analog Current (0 to 250% rated current)
0
12.22
AO1 Analog Output
Gain
1 to 200% 100
0: AVO2
1: ACO2 (analog current 0.0 to 20.0mA)
12.23
AO2 Terminal Analog
Signal Mode
2: ACO2 (analog current 4.0 to 20.0mA)
0
0: Analog Frequency
12.24
AO2 Analog Output
Signal
1: Analog Current (0 to 250% rated current)
0
12.25
AO2 Analog Output
Gain
1 to 200% 100
Group 13: PG function Parameters for Extension Card
13.00 PG Input
0: Disabled
1: Single phase
2: Forward/Counterclockwise rotation
3: Reverse/Clockwise rotation
0
13.01 PG Pulse Range 1 to 20000 600
